How to Install a Lambo Door Kit on your 2005-2009 Mustang

This Mustang Parts Installation Guide Works For

Lambo Door Kit (05-09 All)DOWNLOAD PDF

Tools Required

Installation Time: 4 hours

Installation

lambo-door-kit-05-09-all

Before install

lambo-door-kit-05-09-all lambo-door-kit-05-09-all

Step One, remove positive and negative connections on terminal.

lambo-door-kit-05-09-all

Step Two, open door to full extent & remove door stopper

lambo-door-kit-05-09-all

Step Three, remove door panel & clips that hold

lambo-door-kit-05-09-all

Step four, extend wires by pulling wires forward

lambo-door-kit-05-09-all

Step five, remove fenders and side skirts (bumper if needed)

lambo-door-kit-05-09-all

Step Six, tape doors securely, (as shown above) and begin to remove factory hinges

lambo-door-kit-05-09-all

Step seven, hold hinge up and align holes, hand tighten bolts and check alignment.

lambo-door-kit-05-09-all

Step Eight, adjustment points to align doors.

lambo-door-kit-05-09-all

Step nine, lift door up to install reinforced shock

lambo-door-kit-05-09-all

Step ten, insert shock into lower ball joint and hand tighten into upper "L" bracket.

lambo-door-kit-05-09-all

Step eleven, insert locking pin into base at bottom of the shock.

lambo-door-kit-05-09-all

Step twelve, trim fender edges back until the hinge clears fender.
