Mustang Billet Cruise Control Switch Installation Guide

This Mustang Parts Installation Guide Works For

Modern Billet Polished Billet Cruise Control Switches (94-04 All)DOWNLOAD PDF

Tools Required

  • A Small Flathead Screwdriver
Installation Time: 15 Mins


Left Side Installation

  1. This side is the easier of the two sides to remove.
  2. Simply place the flat screwdriver into the side of the cruise control switch, in between the switch piece itself, and the plastic bezel that is underneath it.
  3. Use the same process in removing this switch as removing the window switches. Take your thumb and place it over the screwdriver, then pull up. The switch should just pop out.Be careful not to remove the rubber piece underneath the switch!The rubber piece is needed so that your cruise control remains operative.
  4. Installation of this is quite simple. Just position the new switch and snap it into place.

Right Side Installation

NOTE:The right switch is actually two different pieces, a top (one section) and a bottom (two section) piece.

  1. Using a small flat headed screwdriver, pop off the existing lower cruise control button first by prying on the side.
  2. Do the same with the upper cruise control switch.
  3. Snap the top switch into place. Simply position the switch and push down.
  4. Do the same with the lower switch.
  5. Check the fitment and make sure nothing feels loose.
