Mustang 5.0 Clutch Pedal Cover ('79-'93 Manual) - Installation Instructions

This Mustang Parts Installation Guide Works For

DOWNLOAD PDF

Tools Required

  • A small pry bar or flat-head screwdriver
  • Mustang 5.0 Clutch Pedal Cover (79-93 Manual)
Installation Time: 15 Mins

Installation

  1. Use a small pry bar or flat-head screwdriver to force the old clutch pedal cover off the pedal. The cover is held on by rubber clips around the back outside edge of the cover.

    Mustang 5.0 Clutch Pedal Cover 79-93 1

  2. Depending on how old the cover is (in my case it was still a stock cover from 1983) the clips may be cracked, making it very possible to break them in the removal process (this is not important unless you’re planning on keeping them). If you are intending to keep these after the process is over, you will want to be extra careful in removing them.
  3. You’re going to want to insert the small pry bar or flat-head screwdriver into the bottom of the clutch pedal first, and follow with prying off the right side. You’ll be able to pull it off easily after this by simply sliding it to the left.

    Mustang 5.0 Clutch Pedal Cover 79-93 2

  4. You’ll notice below that the bottom clip on my clutch cover broke in the removal process. Taking your time is a sure-fire way to keep your old cover's clips in place.

    Mustang 5.0 Clutch Pedal Cover 79-93 3

  5. When you’re ready to install the new one, you’re going to want to put the left side of the cover on first, by sliding it into place.

    Mustang 5.0 Clutch Pedal Cover 79-93 4

  6. Next, bend the top rubber clip over the pedal, followed by the right clip, and finishing with the bottom clip. Push on the cover until you are satisfied with how it is sitting on the pedal, and finish with sitting on the seat and pushing on it with your foot in order to test it out.

    Mustang 5.0 Clutch Pedal Cover 79-93 5

  7. You’re all done! Go take your 1979-1993 Mustang out for a spin and enjoy the thrills of an American muscle car.

    Mustang 5.0 Clutch Pedal Cover 79-93 6

Installation instructions provided by AmericanMuscle customer Trevor Stevens 8.6.10
