(approx) 10 Minutes
Simple installation for anyone.
The JLT V3 Oil Separator is a catch can setup with even more holding capabilities than previously offered through JLT, and it plugs into the intake tract. And it's a great way to protect an engine. It's a simple mod that does some good for all applications. You don't need to have a forced induction set-up to be able to utilize a catch can, but in the case of the turbocharged EcoBoost, it's especially important. A catch can might not be one of the first mods that's on your list or may not even be on your list at all, but it's a very functional piece that has benefits to it and it can do good for even a completely stock motor. I'll talk more about the install later, but I'm gonna call this one a one-out-of-three wrenches in the difficulty meter. So if we go back to the process of an internal combustion engine for a second, I can explain the benefits of an oil catch can like this one here. So the ignition of the air and fuel mixture inside of the combustion chamber is ignited and it forces the piston downwards. There is a small amount of mixture that leaks past the piston rings and into the crankcase. This is known as blow-by. And in that blow-by, there's an oil mist. The blow-by and oil mist will settle in the intake and over time they're gonna form a gunky build-up. Now, technically speaking, there can also sometimes be condensation along with the oil mist and the blow-by. And if you let all this hang out, or worst case this stuff can make into the oil inside of the crankcase. This is not a good thing and it's considered oil contamination and dilution. So you've got your PCV valve to help fight this issue. A PCV valve alone has its own list of weaknesses, and engines have regulations as far as emissions go. So the current set-up as far crankcase ventilation systems means an engine will have detonation or knock when oil is in the combustion chamber. If the knock sensors pick this up, they're gonna pull timing and that's never a good thing. Another thing that happens is carbon build-up on the piston tops and the valves as well. Enter into the scene the oil separating catch can. It's gonna push these gases, the blow-by and the oil misting condensation through a baffle system that's gonna trap the oil and separate it from the other gases. The gases are gonna be allowed to continue through the intake, so they can be burned off and the oil will stay inside the catch can, so it doesn't move on and cause issues for the engine. So this is a single can that mounts on the driver's side of the EcoBoost on the strut tower. Inside, there's a new multi-stage filter that's going to separate the oil from the air and the other gases. The filtering process consists of a fine mesh screen which then passes oil vapors through an aluminum honeycomb filter. The can itself can hold three ounces of fluid, and you'll notice that the better catch cans actually catch pretty much oil. So the larger capacity of this can means that you won't be having to empty it all the time, go a little bit longer between servicing. And the bottom of this can just unscrews when you wanna empty it. It's sealed with o-rings, so it won't leak at all. The kit is gonna include everything that you need for the install here. You have your mounting brackets, so you can mount this. And it's gonna be positioned, so the can is in an easily accessible area. So when you do need to empty it, it isn't gonna be a fight. It's also gonna come with direct-fit silicon hoses that have some pre-installed stock style quick disconnect fittings which make the install easy. It'll be completely plug-and-play. It doesn't get any more straightforward than this. And the can itself is a billed aluminum can that's sealed, like I mentioned earlier, and, of course, powder coated black. As far as price, you're looking at spending between $100 and $200 for this catch can. Now one thing I will say about catch cans in general is to be wary. You wanna make sure that you're getting a good one that will trap as much oil as possible. Some catch cans are just empty container with a few ports, but these kinds are not gonna condense oil vapor and trap as much oil as possible. You wanna make sure that the catch can has an internal baffling collection system like this one does. So the install here is really pretty easy. You're looking at spending an hour tops and it's gonna be a one out of three wrenches in the difficulty meter. You just need some basic hand tools to get this all done, and I'd start by disconnecting your stock line form the PCV valve under the intake manifold on the engine block and behind the throttle body. You can wrap the hoses under the intake for the fitting that's right behind the throttle body, and the rear hose down towards the engine mount. All the hoses will just snap into place after you have them ran and that's all it's gonna take. Mount the separator assembly to the bracket getting your mounting bracket into place. Wrapping things up here, the JLT Oil catch can is a fast and easy way to protect the motor of the boosted S550 from blow-by. You can check it out more online right here at americanmuscle.com.
Subscribe to our YouTube Channel
Features, Description, Reviews, Q&A, Specs & Installation
Fitment: 2015 2016 2017 2018 2019 2020 Details
CA Residents: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
May 20, 2020
one Out of three wrenches too many
This thing looks and fits great in the engine bay, but man, was it nearly impossible to install. You have to somehow reach your hand behind the intake manifold and be able to contort your wrist about three different directions for you to even think of being able to install it that way. The only other access point is from below the engine, and man is that a pain in the butt if you don’t have a lift. We winded up propping the car on three wheels and a jack just to get under there. As soon as we had access, it was about a 5 minute install from that point.Helpful (0)
May 15, 2020
I felt the change. Nothing to do with hp but you can feel the change. The throttle responsiveness is better.Helpful (0)
May 15, 2020
JLT CATCH CAN
Installing the catch was so difficult I had to take it to the shop. Am happy I finally got it done after a year. Because of where the shop put the catch can, I can’t put the engine cover back unless I change the position which the shop advised not to. Emptying the can will be interesting.Helpful (0)
April 20, 2020
I could feel this product working. The performance came back. Like when i first got it. It was relatively easy to install.Helpful (3)
April 01, 2020
Super easy to install about 40 minutes to do looks amazing under the hood Of my ecoboost. Looks and feels high quality materials. I would recommend this to upgrade for any engine set up.Helpful (3)
March 25, 2020
It took my about an hour and half to install due to the difficulty jacking the car up and disconnecting and installing the hoses to the engine block. I had to break the clips on the stock hose to detach the engine block side of the hose. You’ll need an extended flathead screw driver to push in the clips to the hose. Pep boys wanted to charge me $230 which I couldn’t believe to to them having a lift which would’ve taken them 20-30 to do. Over all it looks good under the hood. I would recommend this product rather your stock or modded for longevity of the engine.Helpful (3)
March 21, 2020
Worth the work
Pain in the butt to install but worth it. The lower clip is very difficult to get to and if your using a jack you can't see it.Helpful (4)
March 09, 2020
This is a cool product that can help save a lot of frustration later down the line. If you like to push your eco I strongly recommend this product. Easy install, just make sure you have stands because that lower connection is impossible to get from the top without taking the whole intake manifold off.Helpful (4)
February 11, 2020
Not a ten minute install
The product works fine and is a nice addition, but there is no way this is a ten minute install especially without a lift. The difficulty comes with removing the clip holding the tube near the bottom of the engine. There is no way to get to this clip from above. On a lift it might be much easier to get to and remove the clip. If you only have a jack and stands, it can take a while. If you notice in the video, they don't actually show the clip being removed, they just make it seem like this is an easy task and move on.Helpful (5)
January 26, 2020
Anything that helps keep the engine clean is a no brainer!Helpful (4)
What’s the difference between the Black Oil Separator the Satin one?
One has a black finish the other has a satin finish.
Will this fit my 2020 ecoboost mustang
I dropped the locking clips do I really need them if it's connected really well and tight? Thank you.
Yes, all clips included with the item are required for proper install and function.
How often on average should this be emptied?
JLT advises: "Drain it every 2000-3000 miles and you will never come close to filling it."
My '15 ecoboost has a catless downpipe with tune and I get a lot of smoke out of the exhaust, will this help tame the smoke?
No, the reason for the smoke is due to not having any cats.
Yes, this will work on the 2019 EcoBoost.
Fitment for this product was recently updated, and will fit the 2018 EcoBoost.
This Driver Side JLT V3.0 Black Oil Separator is only intended for installation on the 15'17 Mustang Ecoboost. This will not fit the 2018 Mustang Ecoboost due to the mounting position and fittings.
(approx) 10 Minutes
Simple installation for anyone.
What's in the Box
