Corvette Radar Blind Spot System with Cross Traffic Detection (Universal; Some Adaptation May Be Required)

Product Information

Features, Description, Reviews, Q&A, Specs & Installation

Features

Retrofit Radar Blind Spot Monitoring And Detection System
Works With Any Vehicle With Plastic Fascias Except Metal Bumpers
Based On Automaker Validated Original Equipment Components
Includes Cross Traffic Detection Functionality
Eliminates 95 Percent Of False Triggers Common In Other Systems
Uses Radar To Accurately Obtain Vehicle Speed Instead Of Reading CAN
Compatible With All Vehicle Makes And Models With Plastic Bumpers
Adjustable Audible Buzzer Volume With Hi-Low-Off Switch
Blind Spot Detection Activates At 27 Feet Behind Radar Under 18 MPH Speed Difference
Lane Change Assist Activates At 290 Feet Behind Radar Over 18 MPH Speed Difference
Intelligent Radar System For Vehicle Speed Determination
Blind Spot Monitoring Over Speeds Of 18 MPH
High Accuracy Sensors Detect Moving Objects Of All Sizes
Cross Traffic Function Activates Automatically In Reverse
Includes 21 Foot Main Harness And 6.5 Foot Rear Sensor Harness
Sensor Working Voltage 12 To 24 Volts DC
Power Consumption 250 Milliamp At 12 Volts DC
Operating Temperature Range Negative 40 To 85 Degrees Celsius
Storage Temperature Range Negative 45 To 90 Degrees Celsius
Radar Detection Range 0.15 To 120 Meters
Waterproof Rating IP69
Sensor Mounts Behind Rear Fascia With External Bracket And Screws
Radar Frequency 76 To 77 Gigahertz
Audio Trigger Wires For Left And Right Side Warnings
HMI Working Voltage 12 To 24 Volts DC
Amber Warning Light With Black Trim
Drill In Mounting Type For HMI
Buzzer Mounts With 3M Tape Or Screws
Buzzer Volume Exceeds 85 Decibels With Adjustable Levels
System Fails To Function Through Metal Bumpers
Fits Universal; Some Adaptation May Be Required

Description

Advanced Blind Spot Safety. The Radar Blind Spot System with Cross Traffic Detection enhances vehicle safety by monitoring blind spots and detecting cross traffic while reversing. It uses radar technology for precise speed and object detection to alert drivers to potential hazards, reducing accident risk and improving situational awareness during lane changes and parking maneuvers.

Construction and Appearance. Constructed with high-frequency 76 to 77 GHz radar sensors enclosed in a waterproof housing rated IP69, the system features durable components designed for harsh environments. The HMI displays amber warning lights on a black trim, combining functionality with a clean and professional look suitable for seamless vehicle integration.

Installation. Installation involves mounting sensors behind plastic rear fascias using external brackets and screws, with drill-in mounting required for the HMI unit. Though some technical skill is necessary, the design includes all necessary wiring harnesses to facilitate a straightforward installation process.

Application. Fits universal; some adaptation may be required due to the systemï¿½s incompatibility with metal bumpers. It is compatible with all vehicles having plastic bumpers but will not function properly on vehicles with metal rear fascias.
