- Mustang Headlight w/ CCFL Halo (05-09) - Installation Instructions
$194.99 (pair)FREE Shipping
If you're looking to take a break from the boring factory-style headlights in your '05 to '09 Mustang, then you might wanna consider the Axial Smoked options here, loaded with the CCFL Halos. Now, these DOT approved lights will combine the very aggressive smoked lens on with that bright white CCFL Halo ring off or right around that $200 price point for the pair. Now, installation will involve the smallest bit of wiring here in order to get everything up and running. So, therefore, the site is gonna not just own up to a soft two to three wrenches on the difficulty meter and take you about an hour or so to knock out from start to finish. And if you guys are curious about what kind of wiring is involved, just hang with me for a bit and we'll walk you through the job later in the video. So, the Axials that we have here will feature a two-pronged approach to spicing up the headlights on that early S-197. Now, first and foremost, you're getting that smoke blend, right?Now, I don't have to tell you guys that smoked lights in Mustangs just go together perfectly and, by itself, this feature will be enough to radically change up the appearance of the front end alone. But then factor in the CCFL Halos and that officially takes these lights from mild to wild, which some owners might like others, maybe not so much. Now, if you are into this look, here's what you guys can expect, a bright white halo or ring that's going to illuminate here around the headlight bulb or reflector area when those parking lights are switched on. And that halo is gonna remain on even when your headlights are switched on. And, hey, if you're really wanna make a statement, then you might want to consider pairing these up with a CCFL fog light option, which we do have a few here on the site to choose from as well. Now, as far as your actual bulbs here with the Axials, well, guess what? They do kick in a brand new set of dual elements, each 13 style bulbs.But if you do have a little bit of worry about light output shining through those dark smoked lenses, well, that's something you can always upgrade down the road to something brighter, such as an LED option or something similar. Now, also quick heads-up guys, these things have been both DOT and SAE approved, meaning they are legal for use in all 50 states and again are sold in sets of two.But now let's segue into the installation as promised earlier and, honestly, this one won't be too bad even given the small amount of wiring needed. But as always, to give you a better idea of what I'm talking about, here's a detailed walkthrough along with your quick tool breakdown.The tools used for this install are quarter-inch ratchet, cordless impact driver, 10-millimeter socket, five and a half millimeter socket, a Phillips head screwdriver and a clip removal tool. So, the first step of this install is gonna be to get underneath the hood and to remove the radiator cover at the top in order to get access to the screws and bolts necessary for removing the front bumper.Next, I'm gonna use a clip tool to remove the push pins that hold the rad cover down. Now, I'm gonna use the 10-millimeter socket to remove these two upper bumper bolts. As you can see, I removed the front wheel to gain access to the inner fender liner. I did this to get access to these three screws and these three clips that hold the fender liner in the front to the bumper so I can peel this back and get access to the bolts behind it. Now that I've peeled back my fender liner, I can get access to these two 10-millimeter nuts from the back of the bumper. I can also get to my two plugs that are a little further in. Now, I'm gonna repeat that same process on the driver side. Before I can remove the bumper, I'm gonna pull the three bolts at the back of the belly pan so that I can remove everything all at once. With everything unbolted, I can remove my front bumper assembly. But while I do so, I have to make sure that I either unplug or unclip my fog lights from the light bulbs themselves.There are three bolts that hold the headlights to the vehicle. There are two at the bottom and one at the top. I'm gonna use the 10-millimeter socket to remove those three bulbs and then unplug the connectors from the back. In order to make the halos for these headlights work, I'm gonna need to tap into the running light circuit. I peeled back the looming on the running white wires and I'm gonna tap my power into the red and white wire on the driver side and the black wire also on the driver side. I'll use the provided vampire clips to tap into those two circuits before I install my headlights. Now, I'll just install my power wire from my halo into the factory power wire for the running light and use the vampire clip to close them together. And then I will repeat this with the ground wire. Now, I can feel the double stick tape on the back of the resistor block for the headlights and stick it to my inner frame rail before I make my headlight connection and reinstall the new headlight.Now, I'm gonna repeat the process on the passenger side and make the same electrical connections I did on the driver side. Now, I've got all my electrical connections made and I tested my lights before I go to throw my front bumper back on to make sure that everything works before I button it up. Make sure that you plug your fog lights back in before you install your bumper. Once the bumper's in, you will not be able to access the fog light bulbs.And that's gonna wrap up this review and install for the Axial Smoked Headlights with Halos for your '05 to '09 Mustang. Thanks for watching and, for all things Mustang, keep it right here at americanmuscle.com.
Subscribe to our YouTube Channel
Features, Description, Reviews, Q&A, Specs & Installation
Technical Note. Not intended for use with vehicles equipped with Daytime Running Lights.
Fitment: 2005 2006 2007 2008 2009 Details
CA Residents: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
April 02, 2020
Made in Taiwan?
Just arrived 4/2/20 going to install. But the ballast box looks like something u would buy on Amazon but other than that they look goodHelpful (0)
April 01, 2020
Love these Headlights
My new favorite thing on my car. They were really easy to install as came with all necessary parts. I swapped out the stock bulbs with LED’s and looks amazingHelpful (0)
March 21, 2020
These lights were perfect for my car. After installation I noticed how much more aggressive it made my Mustang look! I love them!Helpful (0)
March 19, 2020
Splicing can be a pain however they looked good. Halos only come on when parked, and I recommend keeping it this way if you want them to last. Went in easyHelpful (0)
March 11, 2020
So i recieved the lights and installed them but the halos aren't turning on. Messaged AM and they said call a Ford dealership to figure out the problem. Not feeling I received any help. My experience is the wiring with the vampire clips arent connecting and its becoming a pain an my arce.Helpful (0)
February 27, 2020
As soon as i put them in my car i fell so in loveHelpful (0)
February 24, 2020
They where so easy to install and where very bright and looked stunning! I only had mine for a day because I totaled my car the day after I installed themHelpful (0)
February 08, 2020
Looks great and pretty easy to install. But I do have to suggest you dont use the vampire clips. Use some butt connectors with heat shrink. I had one halo not working at all and one halo that would work but had bad connection. So i went to butt connectors and no problems. Also dont have to worry about it rusting. But other than that i love the headlights. Also already had bumper off so i installed in about 15min.Helpful (0)
February 04, 2020
AM has awesome prices and great reviews I do recommend looking at what they have to offer.Helpful (0)
January 19, 2020
The headlights are great but took 11 days to get to my house. As many people know, AM has a 3-5 day shipping guarantee on almost all products including these headlights. I shop from AM all the time and this is the one time I have been disappointed.Helpful (1)
So when I buy this product is just one headlight $189.99 or is it the pair as in the left headlight and the right headlight for $189.99?
The $189.99 price that is shown for the Axial Smoked Headlights is for the driver and passenger side headlights together.
Will I be able to see clearly at night ?
The Smoked Headlights - CCFL Halo are a little dark, and if night time visibility is a concern, I would highly recommend an upgraded low/high beam bulb, such as a Sylvania bulb.
I see that it says these are not meant to be run on cars with DRL's. What is the reason for that? I would like to buy these but my province here in Canada requires all cars older than 2005 to be equipped with working DRL's
The Axial Smoked Headlights do not have the necessary components to work as DRLs as well. So they will not be compatible with the stock DRL system in your vehicle.
I have HID headlamps and understand these smoked halo headlamps cannot be used as a direct replacement and that the connectors are different. Is there an electrical difference between the lights? Can I replace the wiring harness connector with the right type and then plug in the smoked halos?
Installing the Axial Smoked Headlights into a car equipped with HID's will require significant rewiring to allow the use of halogen bulbs. The Connector is wired to a ballast, which then wires to and controls the headlamps in HID equipped cars, as opposed to halogen cars which plug directly into the bulb.
White or Blue? So many of the consumer pics show these (this question applies to the CCFL fog lights, too) as glowing white, and some(like your video) show blue. so what are they really? I'm hoping white.... Thanks
They are white. It has a hair of blue-ish look at certain lighting however it is definitely a noticeable white.
Yes, the Vividline LED conversion is going to work with these headlights.
It all depends on what you have your halos connected to. If you are looking to have them act as DRLs for example, you would need to wire them into the parking light.
Axial does not offer any pieces of these lights separately.
These use H13 bulbs, so as long as you find a bulb listed as H13, they will fit just fine. We currently offer item #399697 as our LED H13 option.
These are DOT approved and should not be a problem, but we suggest that you consult your local laws before installing these on your vehicle to be sure.
Please contact your local DMV for information regarding legality in your state.
The smoked portion of the housing cannot be removed, we recommend upgraded bulbs for better visibility.
