DBA 5000 Series XD Cross Drilled Rotor; Rear (15-23 Mustang GT, EcoBoost w/ Performance Pack)Find parts that fit my vehicle
Item 440603
Our Price
$695.20
Military, Medical & First Responders
$34.76 Available in AM Cash Rewards.
Confirm Eligibility
Confirm Eligibility
CONFIRM THIS FITS YOUR VEHICLE!
Saved - View your saved items
We're sorry. We couldn't save this product at this time.
or use
Shop Owners Save More!
Sign up for our dealer program
Product Information
Features, Description, Q&A
Features & Specs
- Rear 5000 Series XD Brake Rotor Features Non Directional Cross Drilled And Dimpled Design
- XD Finish Provides Cooling Benefits Above The HD Finish Along With Enhanced Sports Aesthetics
- XD Utilises A Mix Of Dimples And Drilled Holes To Provide Enhanced Structural Support Above Transitional Cross Drilled Techniques
- Not Recommended For Track Use
- Diameter Is 330 Mm
- Axle Position Is Rear
- Per Car Quantity Required Is 2
- Vane Design Is KP Vents
- Height Is 43.7 Mm
- Brake Disc Thickness Is 25 Mm
- Minimum Thickness Is 23 Mm
- Centering Diameter Is 71.02 Mm
- Number Of Holes Is 5
- Pitch Circle Diameter Is 114.3 Mm
- Surface Design Features Cross Drilled And Dimpled Pattern
- Two Piece Design Consists Of Aluminium Hats And Cast Iron Rings
- Aluma-Lite Hats Made From 6061 T6 Aircraft Aluminium Reduce Unsprung Weight
- Painted Non-Friction Areas Prevent Rust And Enhance Appearance
- Symmetrical Slotting And Drilling Allow Bi-Directional Use
- Thermal Stability Profiling Increases Rotor Stability And Durability
- Kangaroo Paw Vane Design Improves Heat Dissipation And Brake Life
- NAS Bolts And Crimp Nuts Provide Maximum Strength With Minimal Weight
- Cubic Boron Nitride (CBN) Machine Turned Finish Minimizes Disc Thickness Variation
- Thermographic Heat Paint (TGHP) Indicates Braking Temperature And Rotor Fatigue
- Warranty Covers 12 Months, 20,000km, Or 12,000 Miles
- Fits 15-23 Mustang GT, EcoBoost w/ Performance Pack
| Brand | DBA |
| Rotor Location | Rear |
| Rotor Type | Drilled |
Description
High Performance Rotor. The DBA 5000 Series XD Cross Drilled Rotor; Rear is designed to enhance braking performance by providing improved cooling, structural support, and an aggressive sports aesthetic. It is ideal for high-performance street driving and offers an excellent combination of durability and weight reduction for enhanced vehicle handling.
Construction and Appearance. This brake rotor features a two-piece design with high carbon cast iron rings and aerospace-grade 6061 T6 aluminum hats, which reduce unsprung weight and manage heat more efficiently. The rotor surface is uniquely cross drilled and dimpled, combining advanced thermal stability profiling with a painted finish on non-friction areas to prevent rust and maintain a striking appearance.
Installation. Installation is straightforward without any drilling required, as this rotor directly replaces the factory unit. It is designed for ease of fitment with complete assembly options and individual components for economical replacement.
Warranty. This rotor comes with a 12-month or 20,000 km (12,000 miles) warranty, ensuring quality and reliability for road use.
Application. Specifically fitted for the 2015 through 2023 Mustang GT and EcoBoost models equipped with the Performance Pack, providing optimized braking performance without suitability for track use.
DBA DBA52165BLKXD
CA Residents:
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
4.8
Reviews of DBA Brakes Products (45)
Questions & Answers
No questions about this product yet.
Ask the First Question
Will It Fit My Mustang
- Bullitt - 19, 20
- EcoBoost - 15, 16, 17, 18, 19, 20, 21, 22, 23
- GT - 15, 16, 17, 18, 19, 20, 21, 22, 23
- Mach 1 - 21, 22, 23
