Hellion Single Turbo Complete Kit (03-04 Cobra)

Installation Info

What's in the Box

• (1) T76 S-Trim .96AR, F1 Turbine
• (1) Turbosmart Ultragate Wastegate
• (1) TurboXS Race Bypass
• (1) intercooler 24x6x3 (air to air)
• (1) k-member, a-arms, coil over kit
• (1) Caster Camber Plates
• (8) Spark plugs
• (1) K and N air filter RU 5121
• (1) coolant can support rod and nut powdercoated black
• (1) intercooler support bracket/pwd black
• (1) Turbo bracket/ powdercoated black For Large Turbo w/ cut
• (1) Main turbo inlet--- stainless
• (1) Crossover pipe,
• (1) Downpipe, Tube weld flange stainless, Wastegate flange stainless
• (1) Exhaust double barrel
• (1) Cat or straight pipe
• (1) y-pipe
• (1) small wastegate pipe
• (1) intercooler pipe 1
• (1) intercooler pipe 2
• (1) intercooler pipe 3
• (1) boost inlet pipe/polished
• (1) radiator pipe 1 1/4 polished
• (1) Turbo 4" inlet pipe/polished
• (1) 99-01 Power Steering Bracket (modified)
• (1) 03/04 CobraWater Tube (coated)(modified)
• (1) insert for manifold
• (1) HeatShield
• (1) heat wrap roll
• (2) fan heat shields 6x3
• (2) heat shields for double barrel 4x5
• (8) metal zip ties 14" long
• (10) zip ties for ps hose retention/BK
• (1) Mass air meter adapter flange, hardware
• (11) 2.5" T-bolt clamps
• (1) 3 inch v-band clamp for turbo outlet
• (1) adel clamp for a/c line 5/16" hole
• (1) 1 5/8" clamp for wastegate
• (2) 2 inch hose clamps for radiator hose 26-60mm
• (2) breather hose clamps 1/2"
• (4) 4 to 4.5 inch hose clamps
• (2) hose clamps 27-50mm/bypass
• (4) 3/4 inch hose clamps/idle hoses
• (1) 4"/2" long silicone hose pieces
• (1) 4X3.5 silicone hose
• (5) 2.5 inch silicone hose pieces 3" long
• (1) 03/04 Cobra Intake Hose 2.5 X Oval
• (2) 1 3/8" x 3" silicone hose pieces, cut to 2.5"
• (2) 1 1/4 X 2 3/4" long
• (1) #10 straight hose fitting
• (1) #10 90 degree hose fitting
• (1) oil outlet flange
• (1) #10 oil outlet extension fitting
• (1) #10 line 1 foot each/ 25 ft total cut into 1 ft lengths
• (1) 3/8 to #10 oil return fitting
• (1) black breather hose 1/2"--21" long
• (1) punch for oil pan
• (1) 3 ft 7/32 vacuum line for bypass
• (1) brass tee
• (2) ps line splices 3/8"
• (1) ps line hose 10"each/28 ft
• (4) ps line high pressure clamps 3/8"
• (1) oil feed line 47" #4
• (1) 1/4" pipe to #4 90 degree oil feed fitting
• (1) 1/8" pipe to #4 90 degree oil feed fitting.
• (2) metric socket head bolts for wastegate 1" long M8
• (2) 5/16" socket head bolts for wastegate 1" long
• (2) M8x30mm for support bracket
• (2) metric bolts from intercooler to radiator support M6mm x 30mm long
• (4) washers for metric bolts M6
• (3) 1/4" x 3/4" long bolt
• (3) 1/4" nylock nut
• (6) 1/4" washers
• (1) 5/16" bolt to secure adel clamp to boost hose 1/2"long
• (6) 5/16" washer
• (2) M8 x 20mm Metric bolts for oil drain to turbo
• (8) M8 washers
• (2) 10 mm 50mm long metric bolt for manifold
• (2) 10 mm washers
• (1) 3/8 pipe tap
• (4) 3/8" bolts, nuts, and washers for turbo to turbine inlet 1.5" long
• (2) 3/8" bolts and washers for crossover connection 1.75" long
• (3) 3 inch torq clamps for exhaust
• (1) rubber dog bone 1.75" center to center
• (1) hanger for exhaust
• (4) 3/8 bolts, nuts, and washers for y-pipe to mufflers 2.5" long
• (2) turbo bracket spacers aluminum
• (3) 5/16 bolts, nuts, and washers for intercooler support bracket 3/4" long, exhaust hanger
