JLT V3.0 Satin Oil Separator - Driver Side (05-10 GT)

Item 393759
Call a Mustang Enthusiast at 1-877-887-1105
M-F 8:30A-11P, Sat-Sun 8:30A-9P
$0.00
Market Price $166.99 You Save 5% ($7.99)
Our Price

$159.00

FREE Shipping

Will this fit your Vehicle?

Select a different vehicle Help?
Update or Change Vehicle
In Stock Ships same business day.
Ship to: Ashburn - 20149
Sorry, please enter a valid US or CA postal code
We're sorry, zip can't be updated at this time.
    Create a list
    Add to New List

    Saved - View your saved items

    We're sorry. We couldn't save this product at this time.

    Features & Details

    • Reduces Blow-By and Engine Sludge
    • Version 3.0 - 3 oz Capacity
    • Aluminum Honeycomb Filter with Fine Mesh Screen
    • Solid Billet Aluminum Construction
    • Clear Anodized Satin Finish
    • Easy Plug-And-Play Installation
    • Drivers Side (PCV Side) Kit
    • Includes New PCV Line with Quick Connect Fittings
    • Fits 2005-2010 GT and Bullitt Mustangs
    Reduces Engine Sludge. Prevent engine sludge from hampering the power and performance of your 2005-2010 GT Mustang by installing a JLT Version 3.0 Air/Oil Separator. Crankcase exhaust gases (better known as blow-by) is an oily vapor that re-enters through your engines PCV system and will gradually coat the inside of your throttle body and intake manifold. Overtime this oily residue can thicken and become engine sludge which will rob you of power. However, an Air/Oil Separator (sometimes known as a catch can) will capture these blow-by gases before they are able to re-enter the system to prevent the formation of this engine sludge. A JLT 3.0 Separator is a must have upgrade for all GT and Bullitt owners that want to prevent the formation of this sludge in order to maintain peak power and performance.

    Version 3.0. JLT improved on the designed of their old Oil Separator with the introduction of their new and improved Version 3.0. The first big change you will notice is that the Version 3.0 Separator has a larger 3 oz capacity, that is almost double that of their previous model. Another important difference is the filter media. Older JLT Separators used a Ford Motorcraft pre-filter, but now JLT uses a 1/2" thick 1/16th" aluminum honeycomb filter with a mesh stainless steel screen to trap even more fine oil vapors than before to prevent them from gumming up your engine.

    Superior Quality. This JLT Performance Air/Oil Separator is proudly manufactured right here in the USA. JLT CNC-machines their Air/Oil Separator from a solid block of billet aluminum for superior strength. Designed with a rubber o-ring, this Separator will maintain a tight leak-free seal. The base features a knurled texture, so that it can easily be gripped for removal during routine oil changes. JLT then completes their Catch Can in a durable clear anodized satin finish for impressive good looks and long lasting corrosion resistance.

    Easy Installation. JLT Performance engineered their Separator to be installed in under 10 minutes with just basic hand tools. This kit comes complete and includes two PCV lines with stock-style quick-disconnect fittings that allow for an easy plug-and-play installation. All the necessary parts are included, with no cutting or extra modifications required.

    Application. This JLT Performance Version 3.0 Satin Driver Side Air/Oil Separator is designed for use on 2005-2010 GT and Bullitt models. Installs on the driver side, same side as the PCV valve.

    Technical Note. This JLT Air/Oil Separator is not CARB certified, therefore it is not legal for use in California or other states adopting California emission standards. It is intended for off-road use only.

    Fitment: 2005 2006 2007 2008 2009 2010 Details

    MPN# 3013D-C

    CA Residents: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

    What's in the Box
    • (1) Air/Oil Separator
    Installation Info
    Will it fit my Mustang?

      Customer Photos (28) Submit Your Photo

      View All 28 Photos

        Questions & Answers (1)

        1 Top Rated Question

        On the Drivers side setup can the canister be unscrewed and dropped with clearance and or do clamps have to be removed? Thank you.

        • To drain the driver side JLT V3.0 Satin Oil Separator, we recommend disconnecting the quick connect fitting at the intake to allow this to be swung to where there is adequate clearance to unscrew and remove the lower housing without spilling any oil present there.

        Helpful (0)
        Post Your Question

          Customer Reviews (32) Write a Review

          Overall Rating 4.8

          out of 5 stars




          • 5/5

            September 11, 2019

            oil catch can

            does its job and fit was amazing finish and very easy to install

            AudraC

            Year: 2005 Submodel: GT

            Helpful (0)

          • 5/5

            September 03, 2019

            Oil Separator

            Quality is top notch, fitment was perfect. It does exactly what it is advertised to do; separate oil from the crankcase ventilation system.

            RickSolberg

            Year: 2007 Submodel: GT

            Helpful (0)

          • 5/5

            June 17, 2019

            Jude.s oil separator

            easy to put on looks good no issues while installing.

            JudeN

            Year: 2009 Submodel: GT

            Helpful (0)

          • 4/5

            June 09, 2019

            Does the job, but...

            As others have noted, the install puts a slight kink in the hose. At this price point, I expect a better routing method.

            JG183

            Year: 2010 Submodel: GT

            Helpful (0)

          • 5/5

            May 29, 2019

            Quality Construction 2 minute install

            Easy to install and in just a few short weeks has caught a ton on blow by. Definitely needed with a centri blower.

            GregS

            Year: 2010 Submodel: GT

            Helpful (0)

          • 5/5

            April 21, 2019

            Must Install

            Easy install and eliminates gunk buildup on my older girl 124K. Must install, very easy and peace of mind.

            PatB

            Year: 2005 Submodel: GT

            Helpful (0)

          • 5/5

            April 06, 2019

            Looks and works great

            Was not all that happy about allowing oil into my new intake, so I picked this bad boy up. Lines needed to be completely replaced since I have the FRPP intake, but finally got it all figured out and installed and works like a champ.

            David

            Year: 2008 Submodel: GT

            Helpful (1)

          • 5/5

            March 31, 2019

            MIGT07 Project

            Works great fits good and really dresses up the engine bay great job

            MitchO

            Year: 2007 Submodel: GT

            Helpful (0)

          • 5/5

            March 12, 2019

            works great!

            works like the company says!! MUST have to keep your throttle body clean...

            scottnelson504

            Year: 2010 Submodel: GT

            Helpful (0)

          • 5/5

            January 15, 2019

            Jlt oil separator

            It's a nice addition to preventive maintenance ,looks good and removes alot of contamination. I would recommend this product .

            stang6506

            Year: 2007 Submodel: GT

            Helpful (2)

          • 5/5

            October 27, 2018

            Keeping the clean and boosting economy

            Installed these about a month ago and I noticed my fuel consumption improved. They look great under the hood and took about 15 minutes to install. Homerun!

            TonyC

            Year: 2005 Submodel: GT

            Helpful (2)

          • 5/5

            August 27, 2018

            Oil separator

            This JLT oil separator needs to be totally modified if you have the Ford racing intake manifold that cheesy hard plastic tubing that comes with it is not flexible enough to put the separator where it should be I went to Napa auto parts and bought 2 feet of half inch fuel line and cut off the original tubing and used a hose clamp to mount my separator to my cold air intake box and then fitted the fuel line From the intake to the separator and then looped the hose from the separator underneath to the fitting on the valve cover which works perfectly that is the way it should be designed to mount by the manufacturer

            ChrisH

            Year: 2006 Submodel: GT

            Helpful (1)

          • 5/5

            August 25, 2018

            Good

            It is worth the money. Works great. drove hard 300 miles and it was 1/4 full already.

            BrandonE

            Year: 2006 Submodel: GT

            Helpful (1)

          • 5/5

            August 23, 2018

            Worth buying

            Its really worked , I was surprise to see amount of Oil this JLT Oil Separator, separated specially in driver side. I will recommend all 05-09 GT owner should put one in driver side. With my experience you don't need one in passenger side.

            RonC

            Year: 2006 Submodel: GT

            Helpful (2)

          • 5/5

            August 13, 2018

            JLT Air/Oil Separator

            Well made solid aluminum, seems to work. Only have 250 miles on it but seems to be working

            JasonH

            Year: 2007 Submodel: GT

            Helpful (1)

          • 5/5

            June 09, 2018

            Oil Seperator - preventative maintainance

            Added eye candy under the hood. Looks and feels well designed for longevity. Great preventative maintainance to keep your intake from being layered with engine oil over time. Easy to use, take the collector off every month or so to empty out any valve cover "blow by" oil that it collects. Took 2 minutes to install.

            JayM

            Year: 2007 Submodel: GT

            Helpful (3)

          • 5/5

            May 30, 2018

            oil seperator

            Great product. Highly recommend. Catches a good amount of oil.

            BryanG

            Year: 2005 Submodel: GT

            Helpful (3)

          • 5/5

            April 19, 2018

            Nice satin oil separator

            Very nice product, well built and so easy to install it took all of 10 minutes I would definitely recommend this product

            MichelLeBlanc

            Year: 2006 Submodel: GT

            Helpful (2)

          • 5/5

            March 06, 2018

            JLT V3.0 Satin Oil Separator

            Great Looking - Easy to install - Took all of 10 Minutes - Thanks AM

            BIGDADDY

            Year: 2006 Submodel: GT

            Helpful (2)

          • 5/5

            February 22, 2018

            Works

            This unit does exactly what it says. Fits perfectly

            Stang99x

            Year: 2013 Submodel: GT

            Helpful (3)
