Centerforce Corvette DYAD DS Organic/Carbon Twin Disc Clutch Kit with 6-Bolt Flywheel; 26-Spline 413614842 (97-13 Corvette C5 & C6, Excluding ZR1)

Name: Centerforce DYAD DS Organic/Carbon Twin Disc Clutch Kit with 6-Bolt Flywheel; 26-Spline (97-13 Corvette C5 & C6, Excluding ZR1)
Brand: Centerforce
SKU: CV2601
Price: 1816.95 USD
Availability: InStock
Rating: 4.8 (19 reviews)

Product Information

Features, Description, Reviews, Q&A, Specs & Installation

Features & Specs

Dyad DS 10.4 Twin Disc Clutch Developed For Vehicles Requiring Holding Capacity Of 500 To 1300 Ftlbs Torque At Crank
Patented Centrifugal Weight System For Superior Clamp Load Over Stock
Patented Ball Bearing Actuated Pressure Plate Provides Light Pedal Effort
Discs Equipped With Organic Segmented Facings For Increased Holding Capacity
Sprung/Dampened Drive Disc Offers Smooth Drivability
Lightened Billet Steel Flywheel Provides Low Inertia For Quicker Rpms
Designed, Machined And Assembled In The USA
Match Balanced And Ready For Installation Using Included ARP Fasteners
Out Of Package Weight 46.45 Lbs
Material Billet Steel Flywheel / Nodular Iron Pressure Plate / Segmented Organic Friction
Input Shaft Diameter 1-1/8 In
Input Spline Quantity 26
Clutch Disc Diameter 10.4 In
Disc Quantity 2
Disc Material Organic/Carbon Composite
Sprung Disc Type
Segmented Face Disc Type
Counterweight Assist Included
Torque Capacity 1300 Ftlbs
Pilot Bushing Included
Mounting Hardware Included
Series Dyad DS
Assembled In The USA
Alignment Tool Included
Installed Height 2.760 In
Flywheel Crank Flange Register 2.068 In
168 Tooth Gear
Fits 97-13 Corvette C5 & C6, Excluding ZR1

Brand

Centerforce

Clutch Usage

OEM Style/Street

Clutch Disc Material

Organic/Carbon Composite

Clutch Flywheel Included

Yes

Clutch Flywheel Material

Steel

Description

Twin Disc Clutch System. The Centerforce DYAD DS Organic/Carbon Twin Disc Clutch Kit with Flywheel; 26-Spline combines advanced engineering to deliver a high torque capacity solution for performance vehicles. Designed to handle up to 1300 ft/lbs of torque, it improves throttle response and durability in demanding driving conditions. This kit is key for enthusiasts looking to enhance drivability while maintaining smooth clutch operation.

Construction and Appearance. Featuring a billet steel flywheel for reduced rotational mass, this clutch kit incorporates a nodular iron pressure plate and segmented organic friction discs with a carbon composite material. The polished, machined surfaces and precision assembly reflect its quality and performance-oriented construction, ensuring reliability and long service life.

Installation. Installation is straightforward with no drilling required, and all necessary hardware, pilot bushing, and alignment tool included. It’s designed for ease of fitment to compatible vehicles with minimal modification needed.

Application. Specifically engineered for 1997–2013 Corvette C5 & C6 models, excluding the ZR1 variant.

Centerforce 413614842
