SR Performance Adjustable Rear Upper Control Arm (05-10 All)

Market Price $130.90 You Save 9% ($11.90)
Our Price

$119.00

FREE Shipping
  • Item 53155
  • MPN# 53155

Local Install Shops

Quoted installation from $125

View 3 Shops

near 19355 (change)

Sorry, please enter a valid US or CA postal code
We're sorry, zip can't be updated at this time.
In Stock Ships same business day.
Ship to: ASHBURN - 20146
Sorry, please enter a valid US or CA postal code
We're sorry, zip can't be updated at this time.
Choose options to add to cart
    Create a list
    Add to New List

    Saved - View your saved items

    We're sorry. We couldn't save this product at this time.

    Features, Video & Details

    • Better Traction, Faster Launches, Less Wheel Hop
    • On Car Single Adjustable - Perfect for Street or Track Tuning
    • 1.5" Tubular Steel Construction
    • TIG Welded for Strength
    • Black Powdercoated Finish
    • Aluminum Bushings Included
    • Sold Individually
    • Made in the USA
    • Fits 2005-2010 V6, GT, Bullitt and Shelby GT500 Models

    Review & Installation Video

    Review & Install Video

    Hi I’m Justin with AmericanMuscle.com and I’m going to be breaking down 2 rear upper control arm options both from SR Performance, I have with me their adjustable and non-adjustable option, both fitting the 2005-2010 Mustang. SR Performance is a company that’s been earning the respect and attention of a lot of Mustang enthusiasts lately, thanks to their budget friendly yet high quality performance and suspension components for all generation Mustangs. IF you’re not already watching this video on AmericanMuscle.com and you’d like to get back to our site, to read more about SR’s killer lineup, just click on the link below. The job of an upper control arm is to locate the axle side to side and prevent any pinion angle changes otherwise known as axle rap or axle windup. The factory stuff utilizes some pretty soft rubber bushings, which are notorious for flexing or distorting on hard launches, and aggressive cornering which can cause a bunch of wheel hop, and inconsistent handling. If you want to learn more about making your Mustang handle better and reducing your wheel hop, well, then you have to subscribe to our YouTube channel by clicking the link below. Here you can check out numerous suspension overviews on all of our products, in addition to some pretty cool suspension builds that we’ve done to our own cars. Both of the options I’ve got on the table should do an excellent job of dropping your 60ft times, and reducing wheel hop and axle deflection, while increasing your rear end group by using superior materials compared to your factory control arms. The non adjustables here feature a strong TIG welded steel construction, along with these polyurethane bushings which are greasable. Poly bushings will do a great job of reducing any noise vibrations or harshness, that you otherwise might find on the spherical bearings found on the adjustable control arms here. In my opinion this is a great option for someone who enjoys doing some spirited driving with their Mustang, maybe just a few track days, and just wants to replace those soft rubber factory bushings in the control arm. The adjustable option from SR Performance is for someone who is serious about their track performance, and would ultimately like to dial in their optimum pinion angle settings. For only a few bucks more compared to the non-adjustables, you’re getting full on car adjustability, strong TIG welded steel construction, and these spherical hind joints here, which are going to take all the unwanted movement out of your Mustang’s rear end. Both options aren’t terribly difficult to install and should only take you a couple of hours in the garage using some pretty basic hand tools. Whenever you switch out your rear upper control arms I recommend getting your pinion angle checked out just to make sure everything’s within spec, especially if you decide to go with the adjustables. An incorrect pinion angle can cause unwanted traction, wear and tear on your pinion bearing and drive train vibrations. If you’re not quite sure which option would be best for your application, you should get in touch with one of our Mustang experts, you can call them at 855-422-7439, or shoot them an email at support@AmericanMuscle.com. So if you’re on the endless quest to make your Mustang perform better on the street, or at the track then you have to check out a set of these adjustable or non adjustable control arms from SR Performance, right here at AmericanMuscle.com.

    Improves Traction. Everyone knows that you're going nowhere fast if you can't "hook up" off the line, that's why SR Performance designed their Adjustable Rear Upper Control Arm to provide better traction, quicker launches, less wheel hop and as an added bonus improved 60ft times.

    On-Car Adjustable. The SR Performance S197 Mustang Upper Control Arm is on-car single adjustable, thanks to the spherical rod end bearing, allowing you to dial in your suspensions settings "on-the-fly" to be sure you go straight down the track every time.

    Tubular Steel Construction. Made in the USA from TIG welded heavy duty 1.5" steel tubing for superior strength, SR Performance completes their Rear Lower Control Arms with a black powder coat finish for long lasting durability and good looks.

    Aluminum Bushings. This SR Performance upper control arm features an Aurora (heim joint) spherical rod end bearing and aluminum bushings. The result is great traction during straight-line acceleration and predictable grip during hard cornering.

    Application. This SR Performance Adjustable Rear Upper Control Arm with spherical rod end bearing is designed as a direct bolt-on upgrade for all 2005 to 2010 Mustangs, including the V6, GT, Bullitt and Shelby GT500 models.

    Fitment: 2005 2006 2007 2008 2009 2010 Details

    What's in the Box
    • (1) Upper Control Arm
    Installation Info
    Tech Specs
    Will it fit my Mustang?
    • Bullitt - 08, 09
    • GT - 05, 06, 07, 08, 09, 10
    • GT500 - 07, 08, 09, 10
    • V6 - 05, 06, 07, 08, 09, 10

    People Who Bought This Item Also Bought

    Customer Photos (2) Submit Your Photo

    View All 2 Photos

    You Might Also Like

    4 Questions / 6 Answers

    Ask a Question

    I've installed this product along with the sr adjustable lower arms, j m double adjustable panhard bar and the sr springs. With all metal bushings practically, how much noise should be expected in comparison to poly and rubber?

    mdcarlin92

    • Using solid and spherical bushings will significantly increase NVH, as well as increase stress on the control arm mounts under hard acceleration, due to their nearly nonexistent deflection.

      Rob D

    Helpful (0)

    Re-aligning the rear axle? I have heard that you can use this to re-center the rear axle after lowering the car. Is that true?

    MrDakota0

    • NO. An adjustable UCA is used to change the pinion angle. Which you may be necessary depending on how much you lowered your car. However to re-center the rear axle under the car you need an adjustable panhard rod.

      Tony2010

    Show 1 more answer Helpful (0)

    Re-adjusting rear end after lowering? I've heard that you can use this to realign the rear axle of the car. I'm getting the SR Performance lowering springs put on and I've been told that you need something to move it back. Can this do that along with everything else it does?

    MrDakota0

    • NO. As stated in above comments, this only adjust the pinion angle of the axle. You need an adjustable pan hard bar to move the axle back to center.

      Jbenz76

    Helpful (0)

    Do you need the adjustable lower for this to work? Can you use this with lowering SR springs and adjustable panhard bar together? Thanks

    Erok

    • You don't need the adjustable lower control arms to use this upper. When you install adjustable lowers you put to them stock length when you install them. You can also use this with lowering springs and a adjustable panhard bar. The upper adjusts the pitch of your rear end if you need to and gets rid of the unwanted flex along with the better lowers.

      hotrod12

    Show 1 more answer Helpful (0)

    More Products You Might Like

    Customer Reviews (16) Write a Review

    Overall Rating 4.6

    out of 5 stars

    Installation Time:Afternoon

    Installation Cost:$100-$250

    • Handling Improvement 4.375 4.4
    • Fit 4.4375 4.4
    • Bang For Your Buck 4.75 4.8



    • 5/5

      Installation Time: Afternoon

      January 13, 2018

      Sr rear upper control arm

      Good quality, great price, and a must for lowering your mustang. Good fit but it did take a little while to get it adjusted correctly. Overall very happy with product.

      ChrisM

      Year: 2005 Submodel: GT

      Helpful (0)

    • 2/5

      January 11, 2018

      Good looking product

      Well it looks like it would be a good product but the fail to mention that it doesnt have the bushing so you better order it to or youll be waiting on one to come in

      JustinB

      Year: 2010 Submodel: GT

      Helpful (0)

    • 5/5

      Installation Time: Afternoon

      December 10, 2017

      Good upgrade

      I purchased this part to fix my pinion angle after I installed Eibach sportlines and developed a pinion seal leak. The installation instructions were helpful. I had to remove the gas tank strap torx bolts and pry the tank down from where the UCA and Mount are using a pry bar making sure to support the fuel tank. I used ramps to level and load the suspension after installation of the UCA and set the pinion angle to -1 degree (recommended for spherical bearing / aluminum bushings). My Mustang seems faster and tires seem to break loose ALOT easier. I haven’t noticed noise, vibration or harshness yet. I used the stock mount and put loc-tite on all the bolts as a precaution.

      CodyL

      Year: 2006 Submodel: GT

      Helpful (1)

    • 5/5

      Installation Time: Afternoon

      November 15, 2017

      Good

      Needed this peace to help with my one peace driveshaft and did a good job, only struggle was lowering the gas tank with it being in the way

      JulioA

      Year: 2010 Submodel: GT

      Helpful (2)

    • 5/5

      Installation Time: Less than 1 Hour

      October 11, 2017

      Worked Great

      Excellent improvement over a worn out factory one.

      JamieE

      Year: 2007 Submodel: GT

      Helpful (1)

    • 5/5

      Installation Time: Afternoon

      July 18, 2017

      Upper control arm

      The Rear upper control arm really help out a lot with my wheel hop and pinion angle. I would recommend using this part if you have lowered your car.

      MarioR

      Year: 2009 Submodel: GT

      Helpful (2)

    • 5/5

      Installation Time: Afternoon

      June 05, 2017

      hpg

      this is a must if you have lowered your mustang. install was a pain but I pre set and checked pinion angle was -2deg, no more noise in 1st gear and pinion seal leak stopped. any lowered mustang should have pinion angle checked to avoid any damage to drive train. also lost 90 of rear wheel hop good part for the money.

      hpgt

      Year: 2007 Submodel: GT

      Helpful (2)

    • 4/5

      Installation Time: Less than 1 Hour

      March 18, 2017

      Good part

      Nice finish fit was a little tight on the body side mount but its very solid. Zero axle movement!

      MichaelT

      Year: 2010 Submodel: GT

      Helpful (2)

    • 5/5

      Installation Time: Less than 1 Hour

      January 23, 2017

      Did what it was supposed tO

      Put this on my 06 v6 to correct the pinion angle, if you live in an area where rust is a problem be warned it'll make this a pain. The gas tank straps wouldn't break loose and I didn't want to break them to I removed the arm from the bracket itself, also if you torque the bolts to the recommended torque you may need assistance. I didn't weigh enough to torque the bolts under the car so I got em as tight as I could

      Zack

      Year: 2006 Submodel: V6

      Helpful (2)

    • 4/5

      December 10, 2016

      Heavy duty

      Comes pre assembled and greased, heavy duty build quality. Large heim joint. Great price! Would of gave it 5 stars but haven't installed yet. Did I mention great price!

      JohnDoe

      Year: 2007 Submodel: GT500

      Helpful (3)

    • 5/5

      Installation Time: Shop Install

      December 10, 2016

      GOOD PRODUCT.... GOOD VALUE

      I installed adjustable lower control arms at the same time, all spherical rod ends. Only a slight increase in noise and vibrations but that's expected when you replace soft rubber insulators with a much more precise spherical fastener. It's not may daily driver, maybe once a week or weekends. Initial reactions are the car seems much more precise in the corners, and the launch is improved. I haven't had the opportunity to sort and adjust much yet but I think this product will help me dial the GT in for the drag strip as well as track days, autocross or what ever I decide to go do.

      Fastlane

      Year: 2008 Submodel: GT

      Helpful (3)

    • 5/5

      Installation Time: Afternoon

      June 12, 2015

      Good, strong looking piece!

      I received the part in 4 business days, not bad considering it went across the country. Packaging was excellent and piece is solid. Install is easy, relatively speaking. The adjustability will be nice once the car gets lowered!

      Cancun

      Year: 2010 Submodel: GT Las Vegas, NV

      Helpful (1)

    • 5/5

      Installation Time: Afternoon

      December 29, 2014

      Adj Upper

      The product fit beautiful. I am looking forward to the improved stability.

      Tims06GT

      Year: 2006 Submodel: GT Wesley Chapel, FL, USA

      Helpful (0)

    • 4/5

      Installation Time: Shop Install

      Installation Cost: $100-$250

      October 18, 2014

      Nice product

      Nice product had shop install. Would of liked to see better quality. Bang for the buck, I can't complain too much. Good product considering the price.

      Lowdown05stang

      Year: 1995 Submodel: Other Shelbyville, IN 46176, USA

      Helpful (2)

    • 5/5

      Installation Time: Less than 1 Hour

      September 19, 2014

      great bang for your money

      Have to give it to American Muscle for getting this product to me so quickly! Once I opened it I could tell it was much much beefier then the OEM part. Install was rough at first, but once I had the old one off the new went on and was adjusted in less then 30mins. Good strong product and would recommend this to anyone!

      Goochieboy

      Year: 2010 Submodel: GT North Carolina, USA

      Helpful (3)

    • 5/5

      Installation Time: Afternoon

      May 23, 2014

      Upper arm

      Install was easy. Handling improvement was noticeable. Worth the money

      Carlson169

      Year: 2005 Submodel: Other Alden ny

      Helpful (3)
