DBA Corvette 4000 Series XS Gold Cross Drilled and Slotted Rotor; Front DBA42994BLKXS (97-04 Corvette C5; 05-13 Corvette C6 Base)

Product Information

Features, Description, Reviews, Q&A, Specs & Installation

Features & Specs

Front Brake Rotor With A Diameter Of 325 Millimeters
Designed For Front Axle Use
Each Set Requires Two Rotors
Features A Premium Non-Directional Cross Drilled And Slotted Surface Design
Painted Gold Finish On The Rotor Hub For Enhanced Appearance
Utilizes KP Vents With The Unique Kangaroo Paw Design For Improved Cooling Efficiency
Brake Disc Thickness Is 32 Millimeters With A Minimum Usable Thickness Of 30 Millimeters
Includes Five Mounting Holes With A Pitch Circle Diameter Of 120.65 Millimeters
Centering Diameter Measures 70.7 Millimeters
Packaged Weight Is Approximately 10.67 Kilograms With Compact Packaging Dimensions
Constructed From High Carbon Alloyed Iron With Thermal Stability Profiling
Equipped With Cubic Boron Nitride (CBN) Machined Finish To Reduce Disc Thickness Variation
Paint Markings Change Color At Specific Temperatures To Monitor Fatigue And Heat
Drilled Rotor Configurations Are Not Recommended For Heavy Off-Road Or Track Day Use
Fits 97-04 Corvette C5; 05-13 Corvette C6 Base

Brand

DBA

Rotor Location

Front

Rotor Type

Drilled and Slotted

Description

Premium Brake Rotor Performance. The Front 4000 Series XS Gold Brake Rotor delivers enhanced braking efficiency with its cross drilled and slotted design, which improves dust and gas evacuation for a quieter and more responsive ride. Ideal for drivers seeking an upgrade beyond standard OE brakes, it enhances performance and aesthetics with a distinct gold hub finish.

Construction and Appearance. Manufactured from high carbon alloyed iron and subjected to Thermal Stability Profiling, this rotor ensures durability under intense braking conditions. Its unique Kangaroo Paw vane design optimizes cooling through increased surface area and heat dissipation. The rotor features a CBN-machined surface to minimize thickness variation, along with thermographic heat paint indicators for monitoring brake heat and rotor fatigue, complemented by painted non-friction areas to resist rust.

Installation. This rotor is designed as a direct replacement for front axle brake systems with existing mounting configurations. Installation is straightforward for qualified professionals and requires no additional drilling or modification.

Warranty. This product comes with a 12-month or 20,000 km (12,000 miles) warranty, providing assurance of its quality and longevity.

Application. Specifically designed to fit 97-04 Corvette C5; 05-13 Corvette C6 Base.
