BMR Rear Tunnel Brace w/ Safety Loop - Black (05-14 All)

Item 49604
Call a Mustang Enthusiast at 1-877-887-1105
M-F 8:30A-11P, Sat-Sun 8:30A-9P
$0.00
Market Price $195.44 You Save 13% ($25.49)
Our Price

$169.95

FREE Shipping

Will this fit your Vehicle?

Change Vehicle Help?
Update or Change Vehicle
In Stock Ships same business day.
Ship to: Ashburn - 20149
Sorry, please enter a valid US or CA postal code
We're sorry, zip can't be updated at this time.
    Create a list
    Add to New List

    Saved - View your saved items

    We're sorry. We couldn't save this product at this time.

    Features & Details

    • Additional Safety - Rear Tunnel Brace w/ Driveshaft Safety Loop
    • NHRA Legal
    • Made from 1/4" Thick Steel Plate
    • Bolt-On Design
    • Black Hammer-Tone Powder Coat Finish
    • Fits All 2005-2014 Mustangs
    • Made in the USA
    Added Safety. This BMR Rear Tunnel Brace with Driveshaft Safety Loop is NHRA legal to safely contain your Mustangs drive shaft in place in the event of a U-joint or driveshaft failure that could other wise cause your pony to flip over. The NHRA requires the use of a driveshaft safety loop on vehicles running 12.99 or faster in the quarter mile.

    Quality Construction.
    Made in the USA from 1/4" steel plate for strength this rear Tunnel Brace/Safety Loop is then completed with a long-lasting black hammer-tone powdercoat finish, and is designed to be an easy bolt-on using existing mounting holes, no welding or drilling is required.

    Application.
    The BMR Suspension Rear Tunnel Brace with Driveshaft Safety Loop is designed to fit all 2005 to 2014 Mustangs, including the V6, GT, Bullitt, and Shelby GT500 models.

    Technical Note. Care must be taken at full suspension droop when used with one-piece drive shafts.

    Fitment: 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014 Details

    MPN# DSL011H

    CA Residents: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

    What's in the Box
    • (1) Rear Tunnel Brace
    • (1) Safety Loop
    • (4) Bolts
    • (4) Nuts
    • (8) Flat washers
    Installation Info
    Will it fit my Mustang?

      Customer Photos (4) Submit Your Photo

      View All 4 Photos

        Questions & Answers (1)

        1 Top Rated Question

        hi, what is the size of package with this item? (width, length, height, weight) I need this information to calculate shipping costs to my country.

        • The BMR Rear Tunnel Brace w/ Safety Loop will weight right around 13lbs and will be 43.75 x 10.5 x 4.25 in size.

        Helpful (0)
        Post Your Question

          Customer Reviews (14) Write a Review

          Overall Rating 4.1

          out of 5 stars

          Installation Time:Less than 1 Hour

          • Performance Gain 3.3 3.3
          • Fit 4.428571 4.4



          • 1/5

            September 04, 2019

            Waste of money

            It doesn’t fit. Not even close. It hits the driveshaft before you have enough threads to even start the nuts. I called BMR when I ordered it and they said it would fit. Well they were wrong.

            BrentB

            Year: 2012 Submodel: V6

            Helpful (0)

          • 2/5

            May 24, 2018

            Want work with BBK off-road X-Pipe

            This looks like a solid loop system, but it totally will not work if you have a BBK off-road X-Pipe on your car, which I also bought through American Muscle. I live in Alaska so it will be a pain to send this back. You think AM might mention this, especially since they have the list of all mods on my car (I bought most of them there). When purchasing the website indicated that this would fit my car:(

            JosephN

            Year: 2014 Submodel: GT

            Helpful (8)

          • 5/5

            Installation Time: Afternoon

            May 08, 2018

            Quality part.

            The install went pretty easy just did it with my race ramps. I have the SVT package so I need to verify I have it aligned so it does not rub. I need to put more miles on to do this.

            BlueShelby

            Year: 2011 Submodel: GT500

            Helpful (6)

          • 5/5

            Installation Time: Less than 1 Hour

            July 28, 2017

            Great fit, easy install

            15 minute install of a well made stamped part. Finish is done well on all surfaces. Tucks up under the body well with clearance all the way around the drive shaft.

            KevinB

            Year: 2006 Submodel: GT

            Helpful (6)

          • 4/5

            Installation Time: Afternoon

            July 03, 2017

            Tunnel brace with safety loop

            It looks good but when you lift the car off the ground the driveshaft comes in contact with the brace itself. As long as you're not flying over bumps it will be fine

            DaveC

            Year: 2005 Submodel: GT

            Helpful (6)

          • 5/5

            Installation Time: Less than 1 Hour

            March 01, 2016

            added for safety

            I actually had someone install this when I had my o/r pipes installed. I purchased both front and rear loops from AM. I know over kill. I have a VMP GEN2 w79mm pulley, JPC Budget E85 fuel system, etc give or take 700 rwhp, Just in case when I go to the strip

            14gtStang

            Year: 2014 Submodel: GT

            Helpful (7)

          • 5/5

            Installation Time: Less than 1 Hour

            October 25, 2013

            Go With This Brace - Loop!

            I looked through EVERY option for a some driveshaft safety. This is a very nice product. It's well made and fits great - zero issues, and I have welded subframes! This comes with the brace AND loop, which is a far better design than any other I've seen. It's also a good deal vs other loop only products, IMHO. Installed on 2011 GT. About an hour or so, faster if you have a lift.

            pugboy75

            Year: 2011 Submodel: GT Moorestown, NJ

            Helpful (7)

          • 5/5

            Installation Time: Less than 1 Hour

            April 30, 2013

            BMR DRIVE SHAFT LOOP

            Nice quality. easy to install. Need to drop the exhaust clamps to make room To slide it over exhaust. Clean install.

            GT500PAUL

            Year: 2009 Submodel: GT500 ELMA WA

            Helpful (7)

          • 4/5

            Installation Time: Less than 1 Hour

            January 15, 2013

            Peace of Mind

            Installed this rear safety loop along with the front loop at the same time. As with the front loop, this rear loop installs easily, but unlike the front, the driveshaft does not need to come off. I have not had any issues with it rubbing as noted in other reviews with the stock driveshaft.

            OheightMustang

            Year: 2008 Submodel: GT

            Helpful (7)

          • 4/5

            Installation Time: Less than 1 Hour

            October 05, 2012

            DAILY DRIVERS BE CAREFULL

            was easy to install expecially because was installing the al driveshaft at the same time. wanted extra safety after some of the stories i herd about with the origional driveshaft. after a week or two, hit a couple of big bumps with a loud noise, diddn't know if the springs were bottoming out or the driveshaft was hitting the loop. got under the car and sure enough it was scratched. luckly it was only cosmetic, it did not damage the driveshaft. so i left the brace on but took off the loop. it should still protect in case of failure, and checked to see if it would hit the brace. i would almost have to be airborne for it to hit.

            gwhiz

            Year: 2011 Submodel: V6

            Helpful (7)

          • 3/5

            Installation Time: Less than 1 Hour

            September 18, 2012

            Good product

            For Drag Racing ONLY. I used this loop while track racing, which involved kerbs and suspension travel. The driveshaft makes contact with the brace. This is despite lowering the brace by adding washers (As mentioned by the manufacturer) Again, strongly suggest for Drag Racing ONLY

            Kp318

            Year: 2012 Submodel: V6 Detroit, MI, USA

            Helpful (9)

          • 5/5

            Installation Time: Afternoon

            August 01, 2012

            Easy to installed.

            Great quality . I like that the bolt hole line up with the floor pan factory stud. The color is nice in Hammertone finish.

            BlueSteel2012

            Year: 2012 Submodel: GT Saint John New Brunswick, Canada.

            Helpful (6)

          • 5/5

            Installation Time: Less than 1 Hour

            June 30, 2012

            BMR Rear Tunnel Brace and Driveshaft Safety Loop.

            I was installing a new aluminum driveshaft on my 2012 Boss 302 when I thought I should get a driveshaft safety loop because it's required for the horsepower and ET that I'm putting down. I surfed the net and looked at front loops and rear loops and then I came across the BMR piece in the American Muscle online catalog. The BMR attaches to 6 mounting points that are threaded or studs sticking out from the frame that are unused. The only thing missing from the kit are 4-8mm nuts and 2-8mm bolts about 25mm long (1 inch long). I found the needed hardware at Home Depot. I used locknuts and hardened bolts. Installing the brace is straight forward with no obstructions. once bolted into place, the actual loop is easy to install. The loop has slotted mounting holes so you can center the loop in relation to the driveshaft. The way that this BMR brace mounts, it puts the safety loop slightly closer the the middle of the driveshaft than the rear. I can see that at this mounting point there is no need for a second safety loop because you will see that if you have a failure at the front or the rear of the driveshaft there is no danger of it hitting the ground and pushing up through the floor. The brace is a solid piece of steel plate and you can tell that it strengthens the tunnel area where it bolts to the frame. I recommend this piece and would buy it again. American Muscle shipped this piece and I had it within 3 days.

            Dave302

            Year: 2012 Submodel: Boss Dallas, TX, USA

            Helpful (9)

          • 5/5

            Installation Time: Less than 1 Hour

            April 27, 2012

            BMR Driveshaft Safety Loop

            Well made and high quality product. Installation was easy and the part fit very well with my single piece 3.5" driveshaft.

            07VENOM

            Year: 2007 Submodel: GT500 Pittsburgh, PA, USA

            Helpful (7)
